10KV 6300-8000kW VFD

It has the following performance features: power unit bypass, Easily drive a variety of motors, Belt conveyor master-slave control, Flying start function, Efficient and convenient, Keep running at low voltage, Interference-free switching, cyclic soft start, etc.

Get A Quote Download

PREV：10KV 9000-12500kW VFD NEXT：10KV 5000-5600kW VFD

Parameter
Contact Us

Product Summary

Specifications

	Parametric
	Model	RVE1000-10-6300 ~ RVE1000-10-8000
	Voltage	10kV
	VFD power (kW)	6300/7100/8000
	Output current (A)	462/520/577
	Capacity (kVA)	8000/9000/10000
	Size (mm)	1133417002895

Technical Specifications

Input Power
Input line voltage	3.0~35kV(-10%~+10%)
Input voltage fluctuation	-35%~+15%rated voltage
Input voltage frequency	50/60Hz±5%
Input power factor	When the load exceeds 20%, it can reach more than 0.95
Control power	3ph four-wire system 380V, 5~50kVA (according to the VFD capacity)

Output Power
Output line voltage	3.0~11kV
Output frequency	0~300Hz
Output frequency drift	±5%
Output efficiency	≥96%
Output frequency resolution	0.01Hz

Control function
Speed range	0~300H（Motor related)
Overload	120%, 60s （Can be designed according to user requirements)
Control method	VF control/GVC control /Torque control /Vector control
control precision	±0.5%
Load torque characteristics	Square torque load, constant torque load
Acc/ Dec time	0~3200s (Adjust according to load characteristics)
Main protect function	Overvoltage, overcurrent, short circuit, overheating, optical fiber etc

Input & Output capabilities
Digital input	16 ways, can expandable to 32 ways
Digital output	12 ways, can expandable to 28 ways
Analog input	4 ways (0~10V/4~20mA)
Analog output	6 ways(0~10V/4~20mA)
Communication	Standard: Modbus, Optional: Profibus-DP/Profinet,etc.

Display
Display screen	Touch screen, supports Chinese and English operation interface

Transformer characteristics
Temperature protection	130℃ fault
Insulation level	H

Environmental conditions
Protect grade	IP30
Cooling method	Forced air cooling
Maintenance method	Front and back of VFD maintenance
Operating temperature	-10-+40℃, +40~50℃ Derated operation
Storage temperature	-20-+70℃
Humidity	＜95%, No condensation
Vibration	Below 0.9g
Place of use	No corrosion, explosive gas, dust indoors
Altitude	≤1000m, 1000~2000m Derated used, Derate by 1% for every 100m in height. Please consult in advance if the height is higher than 3000m.

System Function

Product Structure

Model Nomenclature

6kV Medium Voltage Drive Specifications and Dimensions

Model	VFD power ( kW )	Capacity ( kVA )	Output Current ( A )	VFD Size ( DDH mm )	Weight ( T )
RVE1000-6-280	280	350	34	202513252480	2.0
RVE1000-6-315	315	400	38	202513252480	2.0
RVE1000-6-355	355	450	43	202513252480	2.1
RVE1000-6-400	400	500	48	202513252480	2.1
RVE1000-6-450	450	560	54	202513252480	2.2
RVE1000-6-500	500	630	61	202513252480	2.3
RVE1000-6-560	560	700	67	202513252480	2.4
RVE1000-6-630	630	800	77	230015002480	2.6
RVE1000-6-710	710	900	87	230015002480	2.6
RVE1000-6-800	800	1000	96	230015002480	2.8
RVE1000-6-900	900	1120	108	230015002480	2.9
RVE1000-6-1000	1000	1250	120	230015002480	3.0
RVE1000-6-1120	1120	1400	135	230015002532	3.3
RVE1000-6-1250	1250	1600	154	230015002532	3.6
RVE1000-6-1400	1400	1800	173	230015002532	3.9
RVE1000-6-1500	1500	1900	183	230015002532	4.2
RVE1000-6-1600	1600	2000	192	230015002532	4.6
RVE1000-6-1800	1800	2250	217	350016002731	6.7
RVE1000-6-2000	2000	2500	241	350016002731	7.0
RVE1000-6-2240	2240	2800	269	440515002895	9
RVE1000-6-2500	2500	3150	303	440515002895	9
RVE1000-6-2600	2600	3300	318	440515002895	9.8
RVE1000-6-2800	2800	3500	337	470516002895	10.2
RVE1000-6-3150	3150	4000	385	743416002916	12.9
RVE1000-6-3550	3550	4500	433	743416002916	14
RVE1000-6-4000	4000	5000	481	743416002916	14.3
RVE1000-6-4500	4500	5800	558	743416002916	15.5
RVE1000-6-5000	5000	6300	600	743416002916	16.7
RVE1000-6-5600	5600	7000	673	927019803438	20.7
RVE1000-6-6300	6300	8000	770	927019803438	20.7
RVE1000-6-7100	7100	9000	870	927019803438	22.2
RVE1000-6-8000	8000	10000	962	927019803438	22.2

10kV Medium Voltage Drive Specifications and Dimensions

Model	VFD power ( kW )	Capacity ( kVA )	Output Current ( A )	VFD Size ( DDH mm )	Weight ( T )
RVE1000-10-280	280	350	20	270013502480	2.4
RVE1000-10-315	315	400	23	270013502480	2.5
RVE1000-10-355	355	450	26	270013502480	2.5
RVE1000-10-400	400	500	29	270013502480	2.6
RVE1000-10-450	450	560	32	270013502480	2.6
RVE1000-10-500	500	630	36	270013502480	2.7
RVE1000-10-560	560	700	40	270013502480	2.8
RVE1000-10-630	630	800	46	270013502480	2.9
RVE1000-10-710	710	900	52	270013502480	2.9
RVE1000-10-800	800	1000	58	270013502480	3.1
RVE1000-10-900	900	1120	65	270013502480	3.3
RVE1000-10-1000	1000	1250	72	270013502480	3.5
RVE1000-10-1120	1120	1400	81	300015002532	3.7
RVE1000-10-1250	1250	1600	92	300015002532	3.9
RVE1000-10-1400	1400	1800	104	300015002532	4.1
RVE1000-10-1500	1500	1900	110	300015002532	4.3
RVE1000-10-1600	1600	2000	115	300015002543	4.4
RVE1000-10-1800	1800	2250	130	300015002532	4.7
RVE1000-10-2000	2000	2500	144	300015002532	4.9
RVE1000-10-2240	2240	2800	162	300015002532	5.1
RVE1000-10-2500	2500	3150	182	300015002532	5.4
RVE1000-10-2650	2650	3300	191	300015002532	5.8
RVE1000-10-2800	2800	3500	202	450016002731	8.5
RVE1000-10-3150	3150	4000	231	450016002731	9.3
RVE1000-10-3400	3400	4250	245	450016002731	9.8
RVE1000-10-3600	3600	4500	260	450016002731	10.2
RVE1000-10-4000	4000	5000	289	720016002895	14.5
RVE1000-10-4500	4500	5800	335	720016002895	15.2
RVE1000-10-5000	5000	6300	364	1103417002895	16.7
RVE1000-10-5600	5600	7000	404	1103417002895	18.5
RVE1000-10-6300	6300	8000	462	1133417002895	18.9
RVE1000-10-7100	7100	9000	520	1133417002895	20.2
RVE1000-10-8000	8000	10000	577	1133417002895	21.5
RVE1000-10-9000	9000	11200	650	1655019803438	41
RVE1000-10-10000	10000	12500	720	1655019803438	41
RVE1000-10-11200	11200	14000	810	1655019803438	41.8
RVE1000-10-12500	12500	16000	920	1655019803438	42.4
